C-NITROX 400

C-NITROX 400 is a Heavy Duty industrial screw compressor that delivers air at a pressure of 10 bar to an OXYSEP 7-15-40 OXYGEN membrane that separates nitrogen and oxygen, up to a maximum of 40 percent oxygen. The enriched air can be compressed to 232 bar in conjunction with a high-pressure compressor. The percentage of oxygen obtained at the outlet can be adjusted up to 40 percent by means of a valve accessible directly on the top of the compressor. The oxygen analyzer allows the correct percentage to be verified by adjusting it using the appropriate valve.

Standard Equipment

  • Electrical cabinet
  • Automatic condensate drain
  • 2 analyzers
  • Thermostat
  • 1 OXYSEP 7-15-40 OXYGEN Membrane

% O2

32%

38%

40%

l/min HP compressor to be connected1

(Heavy Duty 650)

650 l/min
39m3/h
23 cfm

(Heavy Duty 450)

450 l/min
27m3/h
15.9 cfm

(Efficient/Prime line)

315 l/min
18.9 m3/h
11.1 cfm

Notes: operating pressure 232 bar / when using compressors with lower flow rates, the maximum oxygen percentage is always guaranteed.

Engine:
 Electric three-phase 400 V - 50 Hz

Scope:
 1.070 l/min - 64.2 m3/h - 37.7 CFM

Operating pressure:
 10 bar - 145 PSI

Net weight (appr.):
 199 kg - 439 lb

Dimensions (W x D x H):
 98,5 x 72 x 129 cm - 38.8 x 28.3 x 50.8 in
